Specifications:
Dry Axle Weight (approx. Lbs.): 7705
Dry Hitch Weight (approx. Lbs.): 805
Net Carrying Capacity: 1890
Gross Dry Weight (approx. Lbs.): 8510
Gross Vehicle Weight (GVWR) – Lbs.: 10400
Exterior Length (approx. w / hitch): 32’3″
Exterior Height (approx.): 11’11”
Exterior Width (approx.): 8′
Tire Size: ST235/80R16
Load Range: E
Fresh Water Capacity (w/water heater, approx. gal.): 58
Gray Water Tank (approx. gallons): 35/40
Black Water Tank (approx. gallons): 35
LPG Capacity (approx. lbs): 60
Sleeping Capacity: 6
CSA – Canadian Dealers Only: YES
Auto Ignition Furnace (1,000 BTUs): 30
Features / Options
Standard Features
Northwood Built, Independently Certified, Off-Road Chassis
Fully Welded, Thick-Wall Aluminum Frame Construction
One-Piece, Corona Treated, Continuous Fiberglass
Hot, Polyurethane Laminated, Multi-Layered Substrate Walls
High Density Block Foam Insulation
E-Z Lube Axles w/Nev-R Adjust Forward, Self Adjusting Brakes
16″ Aluminum Wheels / Tires & White Mod Spare
Shocks On All Four Wheels
Stabilizer Jacks / MORryde Step Above w/Strut Assist
Ward-Linen Combo Slide / Dinette Slide
All-Conditions/Four Seasons Insulation With R-18 Ceiling
R-15 Reflective Foil Insulation in Roof / Slide
Heated Holding Tanks / Cathedral Arched Ceiling
Aerodynamic One Piece Front Cap w/BackRoad Armor
2 Independently Switched LED Hitch Lights
Easy Access LP Cover / Diamond Plate Bumper Wrap
LED Interior & Exterior Lighting
Exterior Phatt Ladder /Omni-Directional TV Antenna
SLAM Door Latches on Pass Thru Storage Doors
12V Light in Storage Compartment
LPG Quick Connect & Black Water Flush System
Large Exterior Entry Grab Handle / Entry Door Friction Hinge
Exterior Shower / 2 Afox Logo Director’s Chairs
Semi-Automatic Winterization/By-Pass System
10 Gal DSI Gas/Elect Quick Recovery Water Heater
13.5m BTU Air Conditioner w/Condensation-Resistant Ducting
Carefree Travel’R 12V LED Awning w/Adjustable Pitch HW
45 Watt Solar Panel
12-Volt Power Tongue Jack
Outside Speakers/Battery Disconnect
Frameless Thermal Pane Windows
Satellite Ready / Solar Ready
Interior Command Center / Afox Signature Throw Blanket
Bedroom Carpet w/ Pad
Roller Bearing Drawer Glides
Slow Rise Night Shades
40″ 12v LED TV & AM/FM Stereo w/Bluetooth
Smoke, LPG & CO Leak Detectors
Charge Wizard / Digital Thermostat
Tri-Fold Sofa With Decorative Throw Pillows
Booth Dinette / Fan Vent – Kitchen (Exhaust Only)
Solid Surface Kitchen Countertops
Custom One Piece Formed Countertops & Dinette Table
1.5 Cu Ft Over-The-Range, Convection Micro w/Range Hood
Extra Large Fridge (10 Cu Ft) w/ Cold Weather Kit
Arctic Fox Signature Clock & Entry Mat
Solid Surface Bathroom Countertops w/SS Sink
Dayliter Kitchen Skylight w/ Shade
FanTastic Vent (Bedroom)
Porcelain, Foot-Pedal Toilet / Bath Skylight
FanTastic Vent – Bathroom (Exhaust Only)
Glass Shower Enclosure / Garden Pan
NW TruRest Queen Mattress w/ Bedspread
Recessed Storage Headboard
USB Charging Port at Dinette & on Both Sides of Bed
Options
Battery Box Kit
Slide-Out Topper
Ward Slide Topper
FLXguard Main Awning
CSA (Canadian Dealers Only)
24″ 110V LED Smart TV Bedroom
15K Low Pro Air Conditioner w/Ducting
15K Air Conditioner w/ Ducting
2nd A/C (Low Pro 13.5k) – Replaces Bedroom Fan Vent
Powered Scissor Jacks, Front and Rear
10 Gal LPG w/Soft Cover
2″ Receiver Hitch
Free-Standing Table w/4 Chairs
Holding Tank Heat Pads (All Tanks)
Pwr Dual-Motor Sliding Stab Jacks, Front & Rear
Fireplace
50 Amp Service
100 Watt Solar Panel
170 Watt Solar Panel
5 Point Leveling System – HD
Winegard Carryout G2+ Sat Dish (DISH/DIRECT)
Cross-Stitch Sofa 62″
RV BBQ
Rear View Camera
Gateway Router
