Specifications:
Dry Axle Weight (approx. Lbs.):10563
Dry Hitch Weight (approx. Lbs.):2928
Net Carrying Capacity:2809
Gross Dry Weight (approx. Lbs.):13491
Gross Vehicle Weight (GVWR) – Lbs.:16300
Exterior Length (approx. w / hitch):36’10”
Exterior Height (approx.):13’5″
Exterior Width (approx.):8’6″
Tire Size:LT235/85R16
Load Range:G
Fresh Water Capacity (w/water heater, approx. gal.):88
Gray Water Tank (approx. gallons):67
Black Water Tank (approx. gallons):65
LPG Capacity (approx. lbs):80
Sleeping Capacity:4
CSA – Canadian Dealers Only:YES
Auto Ignition Furnace (1,000 BTUs):35
Features / Options
Standard Features
Northwood Built Ironhorse Chassis
Fully Welded, Thick-Wall Aluminum Frame Construction
Corona Treated Fiberglass
Laminated, Multi-Layered Substrate Walls & Floor
High Density Block Foam Insulation
Wide-Body Floorplan/MORryde Step Above w/Strut Assist
E-Z Lube Axles
Heavy Duty Greaseable Suspension / 2″ Receiver Hitch
16″ Aluminum Wheels / Tires & White Mod Spare
MORryde RPB Pin Box / 6 Point Leveling System
Bed Slide / Dinette Slide/ Flush Floor Super Slide
Four Seasons Insulation With R-18 Ceiling
R-15 Reflective Foil Insulation in Roof / Slides
Heated Holding Tanks / Cathedral Arched Ceiling
Aerodynamic One Piece Front Cap
2 Independently Switched LED Hitch Lights
Fiberglass Rear Cap / LED Cap Accent Lights
LED Interior & Exterior Lighting / Rear View Camera Ready
Exterior HD Ladder / SolX 4 – 400 Watt Solar Package
Exterior Convenience Center
SLAM Latch Luggage Doors
Black Water Flush System
Entry Door Friction Hinge
Exterior Shower / 2 Afox Logo Director’s Chairs
16 Gal DSI Gas/Elect Quick Recovery Water Heater
15m BTU Air Conditioner w/Condensation-Resistant Ducting
12V LED Awning w/Adjustable Pitch HW
Omni-Directional TV Antenna
Outside Speakers/Battery Disconnect
Frameless Thermal Pane Windows w/Custom Wood Trim
Generator Ready / Satellite Ready
Electric Power Reel / Digital Thermostat/50 Amp Service
Interior Command Center
Roller Bearing Drawer Glides
Slow Rise Night Shades
40″ 110 LED Smart TV & AM/FM Stereo w/Bluetooth
Smoke, LPG & CO Leak Detectors / Charge Wizard
Free-Standing Table With 4 Chairs
2 Cross-Stitch Swivel Rocker-Recliners
Tri-Fold Sofa With Decorative Throw Pillows
Solid Surface Kitchen Countertops
1.5 Cu Ft Over-The-Range, Convection Micro w/Range Hood
10 Cubic Foot 12 Volt Stainless Steel Refrigerator
Dayliter Kitchen Skylight w/ Shade / Ceiling Fan
Premium Fan Vent w/Remote/Tstat/Rain Sensor (Kitchen)
Solid Surface Bathroom Countertops w/SS Sink
Exhaust Only Premium Fan Vent – Bathroom
Porcelain, Foot-Pedal Toilet / Bath Skylight
Fiberglass Shower / Glass Enclosure / Bathroom Courtesy Light
Telescoping Lighted Vanity Mirror / Lock Box
NW TruRest Mattress w/UltraDeck Sleep System
Premium Fan Vent w/Remote/Tstat/Rain Sen (Bedroom)
Hardwood Dresser Top / Bedroom Starlite w/ Shade
USB Charging Ports & 110 Outlets on Both Sides of Bed
Options
Booth With Dream Dinette – No Charge
Surround-Soundbar
Slide Tray in Pass Thru
Kitchen Slide Topper
Dinette Slide Topper
Bedroom Slide Topper
FLXguard Main Awning
CSA (Canadian Dealers Only)
32″ 110V LED Smart TV Bedroom
15K Low Pro Air Conditioner w/Ducting
2nd A/C (Low Pro 13.5K) – Replaces Bdrm Fan Vent
Holding Tank Heat Pads (All Tanks)
Exterior Entertainment Center
Powered Dual-Motor Sliding Stab Jacks,Rear
Fireplace
King Bed
5.5 Onan Gold LP Generator
SolX 6 + 200 Watts of Solar
SolX 8 + 400 Watts of Solar
SolX 10 + 600 Watts of Solar
Washer/Dryer Combo
Winegard Carryout G2+ Sat Dish (DISH/DIRECT)
(HD Sat-Call For Options)
3000 Watt Inverter w/400AH Lithium Battery
400AH Lithium Battery
FoxForward Multi-plex System
Theater Seating 62″ (Del. Tri-Fold Sofa)
RV BBQ
14 Cu Ft 12V SS Refer (Opt w/SolX 6 Min.)
Rear View Camera
Gateway Router
